Just thought I'd chime in...here's a link to my build, which is very similar to JBaze's:
http://www.bannedcr500riders.com/board/ ... php?t=3653
I ended up using Shanmans front mounts and made my own headstays.
Some pics:
Coil location/mount:
Another shot:
Coil:
Radiators:
Will have to space the right rad due to Y being raised.
Desert tank clears without modification:
Trial fit subframe and tank. Cut off rear pipe mount. Had to modify front pipe mount holes.
Hope that helps! BTW, still riding it since I finished it in late Sept. No problems or issues at all. Good Luck!
